Thermis Log 10T Disposable USB Temperature Data Logger
Temperature Range: -30℃~70℃
Temperature Accuracy: ±0.5℃ at full range (-30℃ to +70℃)
Memory Capacity: Max. 65,000 readings
The Thermis Log 10T Disposable USB Temperature Data Logger is a high-performance, disposable USB temperature data logger that provides convenient and reliable temperature monitoring and data logging. Built-in PDF file generation function, plug the recorder into the PC through the USB2.0 interface and then generate an unmodifiable data report in PDF format. It has a high-precision temperature sensor that provides accurate temperature measurements.
Introduction
Thermis Log 10T Disposable USB Temperature Data Logger has an LCD screen. You can view the real-time ambient temperature, maximum temperature, minimum temperature, and over- or under-temperature alarm information through the display. The thermometer’s full range (-30°C to +70°C) measurement accuracy is ±0.5°C.
The Thermis Log 10T Disposable USB Temperature Data Logger has high sensitivity and is ideal for the transport and storage of sensitive products, especially pharmaceuticals. The recorder is made of food-grade waterproof packaging material, which is compact and thin and can be placed directly with the product without taking up space.
Features
1. Configurable parameters: Its parameters can be preset on our free configuration software according to your needs, and the setting operation is simple.
2. Long battery life and large memory capacity: This USB temperature data logger can work for up to 120 days. Its storage capacity is up to 65000 readings.
3. Easy to place and operate: The small and lightweight disposable USB temperature/humidity data logger can be placed anywhere. It requires no software or drivers to set up or download data.
4. Abnormal state alarm: Once the temperature or humidity exceeds the set alarm range, the disposable temperature and humidity data logger will send out an alarm through the alarm symbol on the LCD screen, and the red LED light will flash.
5. Automatic generation of encrypted reports: After the trip, connect the USB temperature and humidity recorder to the computer, and an irreversible report with charts and tables will be automatically generated, without cables or readers.
6. IP65 Protection Rating: The protective plastic case helps keep the USB temperature/humidity sensor dry and eliminates worries when transporting the product in cold packs, ice, or wet environments.
Specification
|
Model |
Thermis Log 10T |
Type |
Disposable |
|
Display |
LCD, LED |
Run Days |
Max. 90 days
|
|
Sensor |
Internal NTC |
Memory Capacity |
Max. 65000 readings |
|
Temperature Range |
-30℃~+70℃ |
Temperature Accuracy |
±0.5℃ at full range (-30℃ to +70℃) |
|
Resolution |
0.1℃ |
Battery |
3.0V CR2032 |
|
Logging Interval |
1 minute to 2 hours |
Start Delay |
0 second-2 hours |
|
Button |
Start/Stop |
Start Mode |
Manual
|
|
Connection |
USB, NFC (optional) |
Compatible OS |
Windows, Mac
|
|
Weight |
11g |
Dimension |
67mm *27mm *5mm
|
|
Protection Grade |
IP65 |
Certification |
CE, RoHS, EN12830
|
Applications
Freshliance Thermis Log 10T Disposable USB Temperature Data Logger uses Japanese-made sensors and is suitable for pharmaceutical, food, life sciences, refrigerators, medical cabinets, fresh cabinets, freezers, or laboratories requiring high accuracy.
Food industry: Temperature is a crucial factor during food production, transportation, and storage. Thermis Log 10T can be used to monitor the temperature of food in cold chain transportation to ensure food quality and safety. It can help food companies follow food safety standards, and monitor and record food temperature changes for traceability and certification when needed.
Pharmaceutical industry: The quality and stability of pharmaceuticals are closely related to the temperature of the environment. Thermis Log 10T can be used to monitor the temperature of pharmaceuticals during transportation and storage to ensure the effectiveness and safety of pharmaceuticals. It can help pharmaceutical companies follow the Good Manufacturing Practices, and monitor and record the temperature history of medicines to ensure the quality control of medicines throughout the supply chain.
Logistics and warehousing management: In the logistics and warehousing process, especially for goods that need to maintain certain temperature conditions, Thermis Log 10T can be used to monitor and record temperature changes in the environment where the goods are located. Whether in cold chain logistics, refrigerated warehousing, or temperature-controlled logistics, Thermis Log 10T can provide accurate temperature data to help logistics companies and warehouse managers ensure the quality and integrity of goods.
Laboratory Research: In scientific research and laboratory environments, maintaining constant temperature conditions is critical to the accuracy of experimental results. Thermis Log 10T can be used to monitor temperature changes in the laboratory and provide reliable data support. It can be applied to various laboratory scenarios, including biomedical research, materials science and chemical laboratories, etc., to ensure the repeatability and accuracy of experiments.
Healthcare industry: In the medical field, some drugs, vaccines, and biological products have strict temperature requirements. The Thermis Log 10T can be used to monitor the temperature of medical supplies and equipment to ensure their quality and effectiveness. It can be applied to scenarios such as hospitals, clinics, and vaccine transportation to help medical institutions and supply chain managers ensure the quality and safety of medical products.
